Studiomaster CLUB XS12+ 12 Channel Mixing Console With Bluetooth, USB/SD & DSP Effects
DETAILS
Studiomaster CLUB XS12+ Compact Analogue Mixer With DSP & Bluetooth.
The Studiomaster CLUB XS12+ is a 12-channel compact analogue mixing console designed for live sound, band rehearsals, streaming setups, and home studio recording.
Combining portability with professional-grade features, the CLUB XS12+ offers Bluetooth playback, 16 integrated DSP effects, USB/SD recording and playback, and onboard compression—making it ideal for small venues, musicians, content creators, and event spaces.
Now finished in Studiomaster’s striking digital black, the XS+ range also introduces redesigned control knobs and a new DSP footswitch input for hands-free effects control. Whether you're gigging, recording, or presenting, the CLUB XS12+ delivers reliable, high-quality audio with intuitive operation.
Flexible Input Options & Onboard Effects
The CLUB XS12+ includes 12 inputs—8 mono mic/line channels equipped with compression, 100Hz high-pass filters, mute switches, and 3-band EQ, plus two stereo channels with 2-band EQ and AUX support for line-level instruments or media players.
A 16-programme DSP effects engine offers reverb, delay, and modulation presets, now switchable via an external footswitch for live performance control. The onboard Bluetooth receiver, USB/SD media module, and MP3 compatibility allow for convenient audio playback or mix recording.
Comprehensive Monitoring & Output Routing
Balanced XLR main outputs ensure a clean signal to powered speakers or PA systems, while AUX and DSP sends allow routing to monitor mixes or outboard processors. Phono connectors provide extra analogue input/output options, and a stereo return is included with its own level control. A control room/headphone output enables isolated monitoring, and +48V phantom power is available on all mic channels for condenser microphone support.
Studiomaster CLUB XS12+ Key Features:
- 12 Inputs With Flexible Routing: 8 mic/line channels with EQ and compression, plus 2 stereo input channels
- Integrated DSP Effects: 16 onboard effects including reverb and delay, footswitch-compatible
- Bluetooth Playback: Stream music wirelessly from mobile devices
- USB/SD Playback & Recording: Record directly to or play back from memory devices
- 3-Band EQ On Mic Channels: Fine-tune vocal and instrument sound
- 2-Band EQ On Stereo Channels: Tailor the tone of stereo sources
- Compressor & HPF On Mic Channels: Shape dynamics and control low-end rumble
- AUX & DSP Sends: Route to monitors or effects units
- Mute Switches On All Channels: Instantly silence individual inputs
SPECS & DOWNLOADS
Download the CLUB XS PDF User Manual HERE >
Studiomaster Club XS12+ Specifications
- Inputs: 12
- Mic Inputs: 8
- Stereo Inputs: 2
- Mic Gain Range: 6dB to 50dB
- Line Gain Range: 10dB to 34dB
- EIN: -100dB
- Frequency Response: 10Hz – 20kHz (+1/-3dB)
- THD Mic Channel: <0.1%
- Signal To Noise Ratio: 80dB
- Output Levels: Max +26dB (Balanced), +20dB (Unbalanced)
- EQ Bands: Hi 12kHz, Mid 2.5kHz, Lo 45Hz, Lo Cut 80Hz
- USB/SD: MP3 audio playback
- Recording: To USB drive or SD card (128kbps mono)
- DSP Effects: 16 built-in DSP effects
- Power Requirements: 100V – 240V ~
- Dimensions (W x H x D): 415 x 80 x 365 mm
-
Weight: 5.5kg
