Studiomaster CLUB XS10+ 10 Channel Mixing Console With Bluetooth, USB/SD & DSP Effects
DETAILS
Studiomaster CLUB XS10+ Compact Analogue Power With DSP & Bluetooth.
The Studiomaster CLUB XS10+ is a compact yet powerful 10-channel analogue mixing console ideal for live sound, rehearsals, streaming, and home recording.
Combining professional-level features in a portable format, the CLUB XS10+ offers Bluetooth playback, integrated DSP effects, SD/USB recording and playback, and onboard compression, making it a highly versatile tool for small venues, solo performers, content creators, and bands.
Like others in the XS+ range, this mixer features Studiomaster's new digital black finish, improved layout with redesigned control knobs, and the addition of a footswitch socket for toggling DSP effects. Whether used on stage or in the studio, the CLUB XS10+ provides clean, balanced audio with intuitive control.
Flexible Input Options & Onboard Effects
The mixer offers 10 inputs, including 6 mic/line channels with dedicated gain, compression, 100Hz high-pass filter, mute switches, and 3-band EQ for precision tonal control. Two additional stereo channels include 2-band EQ and auxiliary support for playback devices or keyboards.
Onboard, the 16-programme DSP processor includes reverb, delay, and stereo effects, which can now be toggled using a footswitch for hands-free performance control. The CLUB XS10+ also features USB and SD card playback/record functionality and Bluetooth connectivity for wireless audio streaming.
Comprehensive Monitoring & Output Routing
Balanced XLR main outputs ensure clean signal delivery to PA systems, while the mixer’s AUX and DSP outputs support external effects or monitor mixes. Phono input/output connectors and a stereo return provide extra flexibility for routing, and a dedicated headphone/control room output lets you monitor mixes independently. With +48V phantom power available on all mic channels, condenser microphones are fully supported.
Studiomaster CLUB XS10+ Key Features:
- 10 Inputs With Flexible Routing: 6 mic/line channels with EQ, compression, and 2 stereo input channels
- Integrated DSP Effects: 16 built-in effects including reverb and delay, switchable via footswitch
- Bluetooth Playback: Stream music wirelessly from compatible devices
- USB/SD Playback & Recording: Record mixes or play audio directly from memory devices
- 3-Band EQ On Mic Channels: Detailed tone control for microphones
- 2-Band EQ On Stereo Channels: Add warmth and shape to instruments or line-level inputs
- Compressor & HPF On Mic Channels: Control dynamics and reduce low-end rumble
- AUX & DSP Sends: Create monitor mixes or integrate outboard gear
- Mute Switches On All Channels: Instantly remove any input from the mix
- +48V Phantom Power: Supports condenser microphones across all mic channels
SPECS & DOWNLOADS
Download the CLUB XS PDF User Manual HERE >
Studiomaster Club XS10+ Specifications
- Inputs: 10
- Mic Inputs: 6
- Stereo Inputs: 2
- Mic Gain Range: 6dB to 50dB
- Line Gain Range: 10dB to 34dB
- EIN: -100dB
- Frequency Response: 10Hz – 20kHz (+1/-3dB)
- THD Mic Channel: <0.1%
- Signal To Noise Ratio: 80dB
- Output Levels: Max +26dB (Balanced), +20dB (Unbalanced)
- EQ Bands: Hi 12kHz, Mid 2.5kHz, Lo 45Hz, Lo Cut 80Hz
- USB/SD: MP3 audio playback
- Recording: To USB drive or SD card (128kbps mono)
- DSP Effects: 16 built-in DSP effects
- Power Requirements: 100V – 240V ~
- Dimensions (W x H x D): 345 x 80 x 365 mm
- Weight: 5.2kg
