Q-Audio QAMP3204 2-Zone 4/8 Ohm Mixer Amplifier with Bluetooth, MP3 & FM Radio
DETAILS
The Q-Audio QAMP3204 is a powerful 320W low-impedance installation mixer amplifier designed for professional audio applications in bars, restaurants, gyms, and schools.
Delivering 2 x 100W at 8 ohms or 2 x 160W at 4 ohms, this amplifier provides high-quality stereo sound with flexible input options. The integrated mixer supports one music and three microphone inputs, with switchable music sources including a built-in media player, three rear line inputs, and a front-panel 3.5mm jack input for quick access.
Versatile Media Player & Microphone Features
The internal media player supports Bluetooth streaming, an FM tuner with RDS, and USB/SD card playback with up to 16GB of storage. A jingle player allows up to three pre-recorded announcements to be stored and triggered manually or scheduled for automatic playback. Microphone inputs include phantom power, an isolation transformer on Mic 1, and an adjustable auto talk-over function to ensure clear speech over background music.
Flexible Output & Zone Control
The QAMP3204 features a dedicated zone output with independent volume control, assignable to either the master signal or a rear-line input. The two amplifier channels can be configured for stereo or mono operation, with an optional 80Hz high-pass filter to optimize audio for different speaker types. Additional features include a chime sound generator, music-on-hold output, and remote volume control capability via the optional QWALL wall panel (sold separately).
Durable & Installation-Friendly Design
Built for long-term reliability, the QAMP3204 is housed in a rugged 2U 19-inch rack-mountable chassis with detachable rack ears. A silent temperature-controlled fan ensures efficient cooling, while emergency priority input and output mute contacts enable integration with external systems for emergency messaging.
Q-Audio QAMP3204 Key Features:
- 320W low-impedance installation mixer amplifier (2 x 100W at 8Ω, 2 x 160W at 4Ω)
- Built-in media player with Bluetooth, FM tuner, USB, and SD card support
- 3 microphone inputs with phantom power, EQ, and auto talk-over
- 3 rear line inputs plus a front-panel 3.5mm jack input
- Jingle player with three trigger buttons and scheduling options
- 2-band EQ, 5-LED output meter, and master level control
- Zone output with independent volume control and signal assignment
- Selectable 80Hz high-pass filter for optimized speaker performance
- Emergency priority input and output mute contact
- Optional remote volume control via QWALL wall panel (sold separately)
- Silent fan cooling with temperature-controlled speed
- 2U 19-inch rack-mountable metal chassis with detachable rack ears
SPECS & DOWNLOADS
Download the Instruction Manual HERE >
Q-Audio QAMP3204 Specifications
- S/N Ratio: >82dBu (unweighted 22Hz-22KHz)
- Frequency Range: 20Hz-20kHz
- Weight: 8.85 kg
- AC Power: 115/230V~ 50Hz-60Hz (max. 350W)
- THD: < 0.05%
- Power: 2×100/160 @ 8/4 Ohms
- Cross Talk: >65dB
- Dimensions (WxHxD): 483mm x 88.5mm x 228mm
