Q-Audio QAMP240L 2-Zone 100V Mixer Amplifier with Bluetooth, MP3 & FM Radio
DETAILS
The Q-Audio QAMP240L is a 240W 100V line mixer amplifier designed for commercial installations in bars, restaurants, gyms, and schools.
Featuring a built-in media player with Bluetooth, FM radio, USB, and SD card playback, it provides multiple audio sources for background music and announcements. The mixer section supports one music source and three microphone inputs, with selectable line inputs and a front-panel 3.5mm jack for easy access.
Versatile Input and Media Playback Options
The integrated media player offers Bluetooth streaming, an FM tuner with RDS station information, and USB/SD card playback supporting up to 16GB of storage. A jingle player allows up to three pre-recorded announcements to be stored and triggered manually or scheduled for automatic playback. Microphone inputs include phantom power, an isolation transformer on Mic 1, and an adjustable auto talk-over function to lower background music during speech.
Master Controls and Zoning
The QAMP240L features a 2-band EQ, a 5-LED output level meter, and a dedicated zone output with independent volume control, assignable to either the main mix or a rear-line input. A chime sound generator with adjustable volume and an external trigger is also included. Remote volume control is available via the optional QWALL wall panel (sold separately), making it easy to adjust levels in different areas.
Durable and Installation-Friendly Design
Housed in a robust 2U 19-inch rack-mountable metal chassis with detachable rack ears, the QAMP240L is built for reliable long-term use. A silent temperature-controlled fan ensures efficient cooling, while emergency priority input and output mute contacts enable integration with external systems for safety and emergency messaging.
Q-Audio QAMP240L Key Features:
- 240W 100V line installation mixer amplifier
- Built-in media player with Bluetooth, FM tuner, USB, and SD card support
- 3 microphone inputs with phantom power, EQ, and auto talk-over
- 3 rear line inputs plus a front-panel 3.5mm jack input
- Jingle player with three trigger buttons and scheduling options
- 2-band EQ, 5-LED output meter, and master level control
- Zone output with independent volume control and signal assignment
- Emergency priority input and output mute contact
- Optional remote volume control via QWALL wall panel (sold separately)
- Silent fan cooling with temperature-controlled speed
- 2U 19-inch rack-mountable metal chassis with detachable rack ears
SPECS & DOWNLOADS
Download the Instruction Manual HERE >
Q-Audio QAMP240L Specifications
- S/N Ratio: > 72dBu (unweighted 22Hz-22KHz)
- Frequency Range: 20Hz-20kHz
- Weight: 9.55 kg
- Power Handling: 1x 240W @ 40 Ohm
- AC Power: 115/230V~ 50Hz-60Hz (max. 465W)
- THD: < 0.05%
- Cross Talk: > 65dB damping
- Dimensions (WxHxD): 483mm x 88.5mm x 237mm
