Pioneer Professional CM-S54T 4.5" 100V Wall Speaker - Black or White

Original price £139.00 (inc. VAT) - Original price £139.00 (inc. VAT)
Original price £139.00 (inc. VAT)
£139.00 (inc. VAT)
£139.00 (inc. VAT) - £139.00 (inc. VAT)
Current price £139.00 (inc. VAT)
SKU CM-S54T-W
Colour: White
DETAILS

The CM-S54T is a two-way wall speaker with a discreet curved design, wide dispersion, and IP54-rated enclosure. Ideal for background music indoors or in sheltered outdoor areas.

Compact Surface Mount Loudspeaker With Flexible Installation

The Pioneer CM-S54T is a 4.5” two-way surface mount loudspeaker designed for clear, reliable audio in a compact format. Suitable for both indoor and select outdoor applications, this versatile speaker delivers clean highs and rich bass for background music and public address systems.

High-Quality Audio Performance

A 1-inch soft dome tweeter ensures crisp, short-throw high frequencies. Combined with a newly developed Vortex Bass Accelerator, it delivers smooth, warm low-end without distortion.

Simple, Adaptable Installation

The CM-S54T comes with a rigid U-bracket for easy angle adjustment. Its original curved enclosure design blends neatly into a variety of room styles, whether mounted on flat or curved surfaces.

Durable, Weather-Resistant Build

Rated to IP54, this speaker offers protection against dust and splashing water, making it suitable for covered outdoor areas and challenging indoor environments.

Flexible System Compatibility

With built-in transformer taps for 70V/100V line systems and an 8-ohm direct input option, it easily integrates into different sound system configurations.

Pioneer Professional CM-S54T-K Key Features:

  • 4.5” two-way passive loudspeaker

  • Soft dome tweeter for smooth high frequencies

  • Vortex Bass Accelerator for distortion-free bass

  • 120° x 120° conical dispersion

  • IP54 dust and water resistance

  • 70V/100V transformer taps and 8Ω input

  • Supplied with adjustable U-bracket

  • Black or white finish options

SPECS & DOWNLOADS

Pioneer Professional CM-S54T Specifications

  • Loudspeaker type: Two-way passive, reflex-loaded
  • Sold as: Single Speaker
  • Rigging and hardware: 1 × U-bracket, 2 × M6 threaded mounting points
  • Grille: Punched aluminium
  • Enclosure: Polypropylene (PP)
  • Frequency response (-10 dB): 95 Hz - 20 kHz
  • Sensitivity (1W/1m): 87 dB
  • Nominal impedance: 8 Ω
  • Power handling (RMS/Program): 40 W / 80 W
  • Transformer taps (70V): 30/15/7.5/3.75 W
  • Transformer taps (100V): 30/15/7.5 W
  • Dispersion: 120° H × 120° V
  • Maximum SPL: 109 dB peak
  • Driver configuration: LF: 4.5" cone, HF: 1" silk dome
  • Connectors: Euroblock (4 pin)
  • Dimensions (W x H x D): 154.9 x 250.6 x 144.5 mm
  • Weight (per piece): 3.4 kg
  • Environmental rating: IP54
  • Colour options: Black (CM-S54T-K), White (CM-S54T-W)

Pioneer Professional CM-S54T Downloads

Download the spec sheet HERE >

Download the user manual HERE >

}
