HH Audio, Aptur APT-CL63 | 100W High-Performance Column Speaker, 100V
DETAILS
The HH Audio APT-CL63 is a high-performance column speaker designed to deliver exceptional speech intelligibility in acoustically challenging environments.
Featuring six Celestion 2.75-inch AN2775 full-range neodymium drivers, this speaker provides precise directivity, making it ideal for applications such as houses of worship, museums, educational institutions, and corporate settings.
Available in black or white, the APT-CL63 offers a sleek, low-profile design that integrates seamlessly into any space without detracting from the surrounding architecture.
Installation is straightforward with the included pan/tilt wall bracket, featuring six rear mounting points for flexible positioning. The bracket supports four height settings and adjustable downward tilt (0°, 5°, 10°, 15°), along with left-to-right panning, ensuring optimal sound coverage. The integrated multi-tap transformer allows for both low-impedance (Lo-Z) and 70V/100V system compatibility, enhancing versatility in various audio installations.
The APT-CL63 is meticulously engineered to deliver outstanding performance while maintaining a refined aesthetic. Its powder-coated, ribbed aluminium enclosure minimises light reflections, ensuring it remains visually unobtrusive in architecturally sensitive environments.
HH Aptur APT-CL63 Key Features:
- 6 x Celestion AN2775 full-range neodymium drivers for enhanced speech clarity
- 120W AES power handling (240W continuous, 480W peak)
- 91dB sensitivity, with a maximum SPL of 117dB
- Wide 120° horizontal dispersion with a controlled 12° vertical dispersion
- Multi-tap transformer for 8Ω, 70V, and 100V operation
- Six rear mounting points with adjustable tilt (0°, 5°, 10°, 15°) and left-right panning
- Elegant, low-profile design with a powder-coated aluminium enclosure
- Available in black or white to suit different environments
- Ideal for speech reinforcement in highly reverberant spaces
SPECS & DOWNLOADS
HH Aptur APT-CL63 Specifications:
-
System Type: Full Range Column Array Loudspeaker
-
LF Driver: 6 x Celestion AN2775 - T5820 Full-Range Neodymium Drivers
-
100V Power Options: 100W, 50W, 25W, 13W
-
70V Power Options: 100W, 50W, 25W, 13W, 6W
-
Nominal System Impedance: 12 Ohms
-
Power: 120W AES, 240W Continuous, 480W Peak
-
Recommended Amplifier: MZ-140D, MZ-140Q, MZ-280Q
-
Sensitivity (1W/1M): 91dB
-
Max SPL: 111dB SPL, 117W dB SPL (Peak)
-
Frequency Response: 160Hz-20kHz
-
Input Link Connector: 4-pin Euroblock +/- +/-
-
Horiz. Dispersion Angle 1000Hz: 120°
-
Vertical Dispersion Angle 1000Hz: 10°
-
Main Construction Material: Aluminium, MDF with ABS End Cap
-
Finish: Black or white
-
Grille: Black Fine Mesh Perforated Steel with Powdercoated Finish
-
Mounting Bracket: Pan/Tilt bracket
-
Mounting Points: 6 mounting points for included bracket.
-
Unit Dimensions (Hwd): 521mm x 100mm x 150mm
