HH Audio, Aptur APT-CL103 | 100W High-Performance Column Speaker, 100V
DETAILS
The HH Audio APT-CL103 is a high-performance column speaker designed for environments where clear, intelligible audio is essential.
Featuring ten Celestion 2.75-inch AN2775 full-range neodymium drivers in a sleek, tapered aluminium enclosure, it provides precise audio directivity suited to acoustically challenging spaces such as houses of worship, museums, educational facilities, and corporate environments.
Available in black or white, the APT-CL103 blends seamlessly into any setting without detracting from the surrounding architecture.
Designed for easy installation, the APT-CL103 includes a wall-mount bracket with six mounting points in the rear channel, allowing for four height positions and downward tilt adjustments of 0°, 5°, 10°, or 15°. Its slim profile also enables generous left-to-right panning for optimal positioning. Additionally, an integrated multi-tap transformer supports both low-impedance (Lo-Z) and 70V/100V installations, ensuring compatibility with a range of audio systems.
Carefully engineered for both performance and aesthetics, the APT-CL103 minimises unwanted reflections while maintaining a discreet, low-profile appearance. The powder-coated, ribbed aluminium cabinet reduces light reflections, ensuring it remains unobtrusive in visually sensitive environments.
HH Aptur APT-CL103 Key Features:
- 10 x Celestion AN2775 full-range neodymium drivers for precise audio directivity
- 200W AES power handling (400W continuous, 800W peak)
- 93dB sensitivity, delivering a maximum SPL of 116dB
- Wide horizontal dispersion of 120° with a controlled 10° vertical dispersion
- Multi-tap transformer for 8Ω, 70V, and 100V operation
- Six rear mounting points with adjustable tilt (0°, 5°, 10°, 15°) and left-right panning
- Elegant, low-profile design with a powder-coated aluminium enclosure
- Available in black or white to suit different environments
- Ideal for speech reinforcement in acoustically challenging spaces
SPECS & DOWNLOADS
HH Aptur APT-CL103 Specifications:
-
System Type: Full Range Column Array Loudspeaker
-
LF Driver: 10 x Celestion AN2775 Full-Range Neodymium Drivers
-
100V Power Options: 100W, 50W, 25W, 13W
-
70V Power Options: 100W, 50W, 25W, 13W, 6W
-
Nominal System Impedance: 20 Ohms
-
Power: 200W AES, 400W Continuous, 800W Peak
-
Recommended Amplifier: MZ-140D, MZ-140Q, MZ-280Q
-
Sensitivity (1W/1M): 93dB
-
Max SPL: 116dB SPL, 800W dB SPL (Peak)
-
Frequency Response: 160Hz-20kHz
-
Input Link Connector: 4-pin Euroblock +/- +/-
-
Horiz. Dispersion Angle 1000Hz: 120°
-
Vertical Dispersion Angle 1000Hz: 10°
-
Main Construction Material: Aluminium, MDF with ABS End Cap
-
Finish: Black or white
-
Grille: Black Fine Mesh Perforated Steel with Powdercoated Finish
-
Mounting Bracket: Pan/Tilt bracket
-
Mounting Points: 6 mounting points for included bracket.
-
Unit Dimensions (Hwd): 849mm x 100mm x 150mm
