FBT Archon 215S 2x15" Passive Subwoofer, 2000W/4Ω - Black

DETAILS

Powerful architectural subwoofer for extended low-end — the FBT Archon 215S.

The FBT Archon 215S is a powerful passive subwoofer designed for venues that demand deep, impactful bass reinforcement with discreet architectural styling.

Equipped with two custom-designed 15” low-frequency woofers, made in Italy, the Archon 215S delivers high SPL, excellent dynamics and extremely low distortion — ideal for clubs, bars, live music venues and other high-energy environments.

Built from robust Baltic birch plywood and finished in durable textured black paint, the Archon 215S combines elegant design with exceptional performance. An acoustically transparent steel grille with protective cloth ensures the drivers stay protected while blending seamlessly into any interior. A choice of special RAL colours and finishes such as glossy or matte is available to order, along with a weatherproof version for outdoor use if required.

Multiple M10 and M5 threaded rigging points, along with a wide range of dedicated mounting hardware, allow secure and flexible installation. The Archon 215S can be perfectly paired with full-range Archon loudspeakers for a complete system with extended low-end performance.

FBT Archon 215S Key Features:

• Dual 15” Design: Deep, impactful bass from two custom low-frequency woofers made in Italy.
• Architectural Cabinet: Baltic birch plywood finished in textured black as standard.
• Acoustically Transparent Grille: Steel grille with protective cloth for a sleek look.
• Flexible Installation: Multiple M10/M5 rigging points and compatible mounting hardware.
• Professional Connectivity: 2 x Speakon NL4 (in & thru) for reliable system integration.
• High SPL Output: Up to 142dB peak output with tight, punchy low-end.
• Optional Weatherproof Version: Available to order for outdoor installations.
• Perfect System Match: Designed to complement Archon full-range models.


SPECS & DOWNLOADS

FBT Archon 215S Specifications

Download the PDF Data Sheet HERE >

• Configuration: 1-way passive subwoofer
• Recommended Amplifier: 2000W RMS
• Long Term Power: 1000W
• Short Term Power: 4000W
• Nominal Impedance: 4 Ohms
• Frequency Response: 35Hz – 500Hz (-6dB)
• Low Frequency Woofer: 2 x 15” (3” coil) custom LF woofers
• Maximum SPL (Continuous/Peak): 139dB / 142dB (half-space)
• Dispersion (HxV): Omnidirectional
• Crossover Frequency: External active
• Input Connectors: 2 x Speakon NL4 (in & thru)
• Net Dimensions (WxHxD): 900 x 485 x 640 mm (35.43” x 19.09” x 25.19”)
• Net Weight: 50kg (110.2lb)
• Transport Dimensions (WxHxD): 1000 x 530 x 800 mm (39.4” x 20.8” x 31.5”)
• Transport Weight: 60kg (132.3lb)


Manuals & Data Sheets:

FBT Archon 215S Data Sheet
