Ecler ARQIS110i 10" 2-Way Passive Loudspeaker, 300W/8Ω – Black or White
DETAILS
Ecler ARQIS110i Robust, Versatile And Designed For Demanding Installations.
The Ecler ARQIS110i is a premium 2-way passive loudspeaker created to deliver outstanding audio clarity and reliable coverage in permanent installation projects where clear, full-range sound and discreet aesthetics are equally important.
Constructed with a durable MDF cabinet, the ARQIS110i ensures excellent acoustic performance and dependable operation in a variety of commercial settings, including restaurants, retail outlets, educational facilities, fitness studios and worship spaces. It houses a powerful 10” low-frequency driver paired with a 1” rotatable high-frequency compression driver, producing dynamic, balanced sound with a wide 90° x 90° coverage — whether installed vertically or horizontally.
With an impressive power rating of 300 W RMS (1200 W peak) and a frequency response from 55 Hz to 20 kHz, the ARQIS110i easily handles both subtle background audio and more demanding foreground playback with deep bass and crisp highs. The rotatable HF driver, combined with the included VEASY wall bracket, makes positioning simple with flexible pan and tilt adjustability using a single locking screw. A metal safety sling is also supplied for secure fixed installation.
Connection options include both Euroblock and Speakon® terminals, offering professional, secure wiring flexibility. For more mounting choices, an optional U-bracket (sold separately) is available. Finished in black (RAL 9005) or white (RAL 9003), the ARQIS110i blends effortlessly into a wide range of architectural interiors.
Ecler ARQIS110i Key Features:
- Robust MDF Cabinet: Delivers enhanced sound quality with a solid, discreet look.
- 10" Woofer + Rotatable 1" HF Compression Driver: Ensures full-range, clear sound with versatile mounting.
- Includes VEASY Wall Bracket: Simple, secure pan and tilt adjustment with single-screw fixing.
- Dual Professional Connectors: Euroblock and Speakon® for safe, reliable wiring.
- Optional U-Bracket Ready: Additional mounting flexibility for varied installations.
-
Safety Sling Supplied: Added security for permanent installations.
SPECS & DOWNLOADS
Ecler ARQIS110i Specifications
Download the PDF Data Sheet HERE >
- Power Handling: 300 W RMS / 1200 W Peak
- Frequency Response: 55 Hz – 20 kHz (–10 dB)
- Sensitivity: 93 dB (1W/1m)
- Maximum SPL: 120 dB continuous / 126 dB peak
- Recommended Amplifier Power: 600 W RMS
- Drivers: 10" woofer, 1" rotatable compression driver
- Nominal Impedance: 8 Ω
- Crossover Frequency: 2.8 kHz
- Recommended High-Pass Filter: 60 Hz, minimum 12 dB/octave
- Connection Type: 1 x Euroblock & 1 x Speakon®
- Enclosure Material: MDF
- Grille Material: Steel
- IP Rating: IP31
- Flying Points: 6 x M6 & 2 x M8
- Operating Temperature: –10 °C to 40 °C
- Dimensions (WxHxD): 294 x 460 x 315 mm
- Weight: 11.8 kg
- Included Accessories: VEASY Wall Bracket, Allen keys (3mm/4mm/6mm), metal safety sling
-
Optional Accessories: U-Bracket (ARQ110UB)
