Cloud Electronics MA60 60W Mixer Amplifier 1/2 Rack Size (4Ω)
DETAILS
Cloud Electronics MA60 – Compact 60W Mixer Amplifier for Low-Impedance Systems.
The Cloud MA60 is a versatile single-zone mixer amplifier, designed for commercial audio installations in retail, hospitality, licensed premises, and entertainment venues. With a compact half-rack, 2U design, it delivers 60W at 4Ω, making it ideal for background music, paging, and general-purpose audio applications where space is limited.
Flexible Input & Control Options
The MA60 features four line inputs and an electronically balanced mic input, offering seamless integration with music sources, microphones, and external paging systems. A dedicated 3.5mm jack input (LINE 2) allows direct connection of MP3 players, laptops, and mobile devices, ensuring ease of use in various applications. Additionally, the gain trims on all inputs allow fine-tuning for optimal performance.
Expandable & Remote Control Capabilities
For enhanced control, the MA60 is compatible with Cloud RL-1 (music level) and RSL-4 (music level & source selection) remote controllers, allowing convenient operation from remote locations. A transformer-isolated auxiliary output with independent mic and music level control is included, making the unit ideal for telephone MOH (music on hold) systems.
Reliable & Compact Solution for Commercial Installations
Built to Cloud’s high standards of sound quality and reliability, the MA60 is a compact yet powerful solution for small to medium-sized venues requiring high-quality background music, paging, or mixed audio distribution. Optional rack mounting kits (RE-S & RE-L) allow flexible installation options to suit any setup.
Cloud Electronics MA60 Key Features:
- 60W single-zone Class-D amplifier (4Ω output)
- Four-input mixer with electronically balanced mic input
- 3.5mm jack input (LINE 2) for MP3 players, laptops, etc.
- Gain trims on all inputs for precise level control
- Transformer-isolated auxiliary output for MOH systems
- Compatible with Cloud RL-1 and RSL-4 remote controllers
- Compact 2U, half-rack size – optional rack mounting kits available
- Reliable, energy-efficient performance
SPECS & DOWNLOADS
Download the Product Data Sheet HERE >
Cloud Electronics MA60 Specifications
Line inputs
Frequency Response:
-
Low-Z output: +0/-1 dB, 20 Hz to 20 kHz (65 Hz filter out)
Distortion
- Low-Z output: <0.05% @ 1 kHz, 1 dB below full power (80 kHz bandwidth)
- High voltage output: <0.05% @ 1 kHz, 1 dB below full power (80 kHz bandwidth)
- Sensitivity: 195 mV (-12 dBu) to 2.0 V (+8 dBu)
- Input Gain Control: 20 dB range
- Input Impedance: 47 kohms
- Headroom: >20 dB
- Noise: -93 dB, 22 Hz to 22 kHz; measured at speaker output, relative to full power
Microphone inputs
- Frequency Response: Low-Z output: -3 dB @ 100 Hz (3rd. order filter); -1 dB @ 20 kHz High voltage output: -3 dB @ 100 Hz (3rd. order filter); -2 dB @ 20 kHz
- Distortion: <0.05% @ 1 kHz, 1 dB below full power (80 kHz bandwidth)
- Gain: 40 dB range
- Input Impedance: >2 kohms (balanced)
- Phantom Power: 15 V, switchable per-input by jumpers
- Headroom: >20 dB
- Noise: -127 dB EIN, 22 Hz to 22 kHz (150 ohms)
Outputs
-
Output Power: Low impedance output: 60 W @ 1 kHz & <0.07% THD+N
- Equalisation: HF: +/-10 dB @ 5 kHz LF: +/-10 dB @ 100 Hz
- Protection: Dynamic level signal limiter max gain reduction of 20 dB, Thermal protection, IV limiting & short circuit protection, Switch on delay
Physical & Dimensions
- Power input: 230 V, 115 V, 100 V versions available
- Fuse Rating: 230/120 V - T2A H
- Fuse Type: 20 mm x 5 mm
- Cooling: Convection cooled, vents top and bottom
- Dimensions (w x h x d): 213 mm x 88 mm (2U) x 278 mm (plus connectors and knobs)
- Shipping Dimensions (w x h x d): 270 mm x 140 mm x 380 mm
- Weight: 3.7 kg
- Shipping Weight: 4.35 kg
