AUDAC SMQ1250 - WaveDynamics™ 4 x 1250W Quad-Channel Power Amplifier 4-8Ω
DETAILS
The Audac SMQ1250 is the flagship model in the SMQ Series, delivering 4 x 1250W of Class-D power with WaveDynamics™ DSP for the most demanding professional installations.
The Audac SMQ1250 is the most powerful amplifier in the SMQ range, providing an impressive 4 x 1250W of Class-D amplification or 2 x 2500W in bridged mode. Designed for large-scale, high-demand installations, it is ideal for stadiums, theatres, arenas, live events, and large-scale multi-zone audio systems.
Its integrated WaveDynamics™ DSP processor and 2.5” LCD display make system configuration and tuning simple, offering tools such as Butterworth, Bessel, and Linkwitz-Riley filters, a 7-band parametric EQ, delay, and dynamic bass boost. User and Administrator access levels can be password- or USB-key protected to prevent unauthorised changes.
The SMQ1250 ensures system reliability with per-channel output power limiters and comprehensive loudspeaker protection. Connectivity options include XLR and terminal block inputs with link-through, plus SpeakON-compatible and Euroblock outputs. For seamless integration, it features RS232 control and an optional Dante™/AES67 expansion module for low-latency, high-quality networked audio streaming.
The amplifier is also TouchLink™ and AUDAC Touch™ compatible, enabling complete remote control from a smartphone, tablet, or computer. The Scroll-Push™ user interface offers intuitive navigation and adjustments directly from the front panel.
AUDAC SMQ1250 Key Features:
- Flagship Power Output: 4 x 1250W with 2 x 2500W bridged mode for the most demanding applications.
- WaveDynamics™ DSP: Built-in loudspeaker management with EQ, filters, delay, and presets.
- Advanced Processing: 7-band parametric EQ, bass boost, and system tuning capabilities.
- Flexible Connectivity: XLR & terminal block inputs with link-through, SpeakON-compatible & Euroblock outputs.
- Optional Dante™/AES67 Expansion: High-quality, low-latency audio over Ethernet.
- RS232 Control: Simple integration into third-party control systems.
- TouchLink™ & AUDAC Touch™ Support: Remote configuration and virtual zone control.
- Scroll-Push™ Interface: Intuitive on-panel navigation and control.
-
Speaker Protection: Per-channel output power limiter and USB-loadable preset
SPECS & DOWNLOADS
Download the Product Data Sheet HERE >
AUDAC SMQ1250 Specifications:
- Amplifier Type: Class-D
- Channels: 4, bridgeable to 2 x 2500W
- Output Power (AES): 4 x 1250W @ 4Ω, 4 x 630W @ 8Ω, 2 x 2500W @ 8Ω bridge
- Frequency Response: 20 Hz – 20 kHz (±3 dB)
- Signal-to-Noise Ratio: >95 dB
- THD+N: <0.05% (1/2 Rated Power)
- Crosstalk: >70 dB (@1 kHz)
- Inputs Sensitivity: -19.5 dB ~ 27 dB
- Input Impedance: 10 kΩ balanced
- Input Connector: XLR & 3-pin Euro Terminal Block (3.81 mm)
- Output Connector: SpeakON & 2-pin Euro Terminal Block (5.08 mm)
- Common Mode Rejection: 70 dB
- Damping Factor: >200
- Protection: DC, short circuit, overheat, overload, signal limiting, power limiter per channel
- Access Levels: User & Administrator via password / USB-key
- Cooling: Temperature-controlled fan
- Operating Temperature: 0° ~ 40° @ 95% humidity
- Power Supply: Switching mode AC 115–240V, 50/60Hz
- Dimensions: 482 x 88 x 420 mm (W x H x D)
- Weight: 9.76 kg
- Mounting: 19” rack, 2 HE
- Construction: Steel
-
Colour: Black
