Cloud BT-2F Bluetooth Facility Input Wall Plate (Black or White)
DETAILS
The Cloud BT-2F Provides Seamless Bluetooth Audio Streaming Into Any Cloud System With a Facility Port Connection.
The Cloud BT-2F is a Bluetooth-enabled facility input wall plate designed for use with Cloud amplifiers and mixers equipped with an RJ45 Facility Port. It allows wireless streaming of audio from compatible devices such as smartphones, tablets, or laptops directly into a defined zone, making it an ideal addition for commercial sound systems in hospitality, retail, education, and leisure environments.
Installation is straightforward — the BT-2F connects to a host unit via a single screened Cat 5 cable, which carries both power and balanced audio. This ensures a neat, reliable, and professional setup with minimal cabling requirements. The device features a single-button pairing operation and can be configured for either secured or unsecured connection modes, depending on your installation needs.
The BT-2F outputs a mono-summed signal (L+R) to the connected Cloud host unit and integrates seamlessly with a wide range of Cloud products, including the Z4MK4, Z8MK4, 46-120MK2, 46-240, MA40, MA80, and MPA series. When used with the optional Cloud FPA-1 adaptor, it can also function as a global line input across multiple zones — offering flexible input management throughout your audio system.
Available in black (BT-2FB) or white (BT-2FW) finishes, the BT-2F blends discreetly into any décor while delivering dependable Bluetooth streaming performance for professional installed sound application.
Cloud BT-2F Key Features:
- Wireless Audio Streaming: Allows Bluetooth audio input from smartphones, tablets, and laptops into Cloud host systems.
- Simple Installation: Connects to the host unit via a single screened Cat 5 cable carrying both power and audio.
- Mono Audio Output: Routes a summed L+R mono signal to the host unit.
- Secure or Unsecured Pairing: Configurable connection mode for flexible use across different applications.
- LED Status Indicator: Bi-colour LED displays pairing status and streaming activity.
- RF Power Adjustment: Adjustable signal strength to prevent accidental inter-room connections.
- Micro USB Port: Allows plate naming for easy system identification.
- Expandable Configuration: Can be daisy-chained with LM-2 remote modules or RSL-6/RL-1 control plates.
- Flexible Integration: Compatible with Cloud Z-Series, MA-Series, and MPA-Series amplifiers and mixers.
- Professional Finish: Available in black or white, fits standard UK single-gang back boxes (minimum depth 35mm).

SPECS & DOWNLOADS
Cloud BT-2F Specifications:
- Model: BT-2F (available as BT-2FB Black / BT-2FW White)
- Connection Type: RJ45 Facility Port (via screened Cat 5 cable)
- Output: Mono-summed (L+R) balanced audio
- Bluetooth Modes: Secured / Unsecured (installer selectable)
- LED Indicator: Bi-colour (pairing and streaming status)
- RF Power Control: Adjustable at installation
- USB Port: Micro USB for naming
- Mounting: UK single-gang back box (85 x 85 mm, 35 mm depth minimum)
- Compatible Cloud Units: Z4MK4, Z8MK4, 46-120MK2, 46-240, MA40F/T/E, MA80FT/E, 46-80/T, MPA120MK2, MPA240MK2
- Optional Accessory: FPA-1 adaptor for global line input configuration
